- 1 x 6040Z-2200W USB 4 Axis CNC Router machine
- 3 x Axis stepper motors
- 1 x 2.2Kw water cooled spindle
- 1 x 2.2 Kw Inverter
- 1 x the rotary axis
- 1 x Control box(4 axis)
- 1 x USB cable
- 1 x Power cable
- 1 x Tool box and tools
- 2 x Connect wires
6040Z-2200W USB Mahc3 4-Axis CNC engraving machine
The 6040Z-1500W/USB CNC engraving machines make it fast and easy to engrave or scribe a wide variety of materials. Spindle speed can be varied between 3,000 and 24,000 rpm for engraving a wide variety of materials, including wood, urethane foam, plastic, acrylic, and light metals such as brass and aluminum.
1) Click the “starter” in mach3 turn on the spindle and then click again will turn off,and click the speed button will change speed too.
2) Input the M3 in Mach3 spindle setting to turn on the spindle and input M5 will turn off,and input S15000 the spindle will work at 15000rpm speed.
Add M3 S18000 in the beginning of engraving file and M5 at the end,the spindle will work at 18000rpm speed and stop when finish work.
3)The aluminium table is not ready very level to the spindle,it need customer yourself milling a flat board under your work piece
Max. working stroke: XYZ=375×575×68mm
Acceptable material thickness: ≤95mm
Frame Material: 6061-T5 extruded aluminum alloy
Rail type: Chromeplate shaft+Linear Bearings
Screw Type: Ball screw,Diameter 16mm,screw thread pitch 5mm
Mechanical Resolution: X Y Z-axis : 0.0025 mm/step
Positioning accuracy: 0.05mm
Spindle Motor: Powerful Brushless frequency spindle,1500W
Revolution Speed: 3000~24000rpm/min
Collet type: ER11(equipped with 6mm collet)
X Y Z Motor: Stepper Motor 57BYGH76-3A
Stepper Drives: High performance,Each axis independently driven
Feed rate: 300~5000mm/min
Communication Interface: USB2.0 (Please use Mach3 control)
Command Code: G code/.nc/.ncc/.tab/.txt
Power Supply: Input 220V~240VAC (50/60Hz),or 100~120VAC
Operation Environment: Temp: 5°~40° C;
Humidity: 35 to 80%
Weight: 58kg (Including packaging )
How to use:
Please read the English user manual to see how to set up the software and how to use this machine.
1.Assembling and locating the CNC machine on steady desk well.
2.Make sure that your computer has a on-board parallel port output.
3.Installing a CNC control software and Drive such as the MACH 3 or EMC2 on your computer.
4.Connecting the control box with the CNC machine and you computer.
5.Fllowing our manual or guideline to set uo the software.
6.You can enjoy making you dream with using our CNC machine now.
